крест AL-DRV 3/8 "(VAU) WITH Pressure REGULATION 50-250 BAR

Production:

Гидролизер, символ: 1.35.06.010.1

Application:

it is widely used in hydraulic systems in agriculture, horticulture, forestry, construction and broadly understood industry.

Principle of operation:

The cross-overflow (safety) valve is used to limit the maximum pressure on two inputs of the receiver. It is an ideal protection against sudden Pressure surges and enables setting different pressures on two inputs of the hydraulic system

предназначен для контроля давления на цилиндрах в передних погрузчиках и вилочных погрузчиках, а также для плавного торможения гидравлических двигателей. A very popular valve in wrappers, drills, augers, loaders, loaders and others.

Connection:

Connect one side of V1 and V2 to pressure lines E. g. in the hydraulic distributor. Аналоговые выходы на другой стороне V1 и V2 к приемнику подключения портов, E. g. двойной действующий цилиндр или гидравлический двигатель.

Technical data:

Maximum flow: 45 л / мин Number of hydraulic holes in the body: 4 Internal threads in the body: 3/8 " [BSP] Боди материал: galvanized steel Maximum allowable pressure: 350 bar Overflow valve factory setting: 130bar Overflow valve adjustment: 45 бар (per full turn) Вес: 1 кг

температурный диапазон и тип масла:

Permissible ambient temperature: -40 C до +60 C Permissible oil temperature: -15 C до +80 C Oil Type: Mineral oil-based hydraulic oil

Hydraulic diagram of the cross overflow valve (рис. ):
