Corteco driveshaft уплотнения левой и правой стороны - 2 pcs
улей>
Application:
Opel Zafira a 1998 - 2005
1.6 16v - X16XEL / Z16XE - 74kw / 101hp
1.6 CNG - Z16YNG-71kw / 97hp
1.8 16V - X18XE1-85kw / 116hp
1.8 16V - Z18XE-92KW / 125hp
улей>
Opel Zafira B 2005 - 2012
1.6-Z16XEP-77kw / 105hp
1.6-Z16XER / A16XER - 85kw / 115hp
1.6 CNG - Z16YNG-69KW / 94hp
1.8 - Z18XER / A18XER-103kw / 140hp
1.8-Z18XEL-88kw / 120hp
F17 manual gearbox
Specification:
number of gears: 5
gear controls: джойстик (Zafira A) / lines (Zafira B)
amount of oil: 1.6 L
улей>
!!! After 2012, The F13 and F17 gearboxes use a different oil with the number 1940004 !!!
oil change:
differential cover
датчик обратной передачи
overflow plug
draining the oil Fig. no. 1 - oil from the gearbox is drained by unscrewing The differential Gear cover
pouring fresh oil - there are two methods: the first by unscrewing the reverse Gear sensor Fig. no. 2 Pour the oil until it appears in the overflow plug ,The second pour oil through the overflow plug until the oil spills out
